KD125

Features: `Number of LCD drive outputs: 120 COM/SEG`Supply voltage for LCD drive: Max +16V`Supply voltage for the logic system: +2.4 to +4 V`LCD display duty selectable by control register`8 LCD Configurations: 0COM/120SEG, 32COM/88SEG, 48COM/72SEG, 64COM/56SEG, 80COM/40SEG, 96COM/24SEG, 112COM/8S...

product image

KD125 Picture
See larger image
SeekIC No. : 004384882 Detail

KD125: Features: `Number of LCD drive outputs: 120 COM/SEG`Supply voltage for LCD drive: Max +16V`Supply voltage for the logic system: +2.4 to +4 V`LCD display duty selectable by control register`8 LCD Con...

KD125 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
KD125
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/12/30

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

` Number of LCD drive outputs: 120 COM/SEG
`Supply voltage for LCD drive: Max +16V
`Supply voltage for the logic system: +2.4 to +4 V
`LCD display duty selectable by control register
`8 LCD Configurations: 0COM/120SEG, 32COM/88SEG, 48COM/72SEG, 64COM/56SEG,
   80COM/40SEG, 96COM/24SEG, 112COM/8SEG, 120COM/0SEG.
`Low power consumption and low output impedance
`Built- in LCD voltage regulator and booster circuit (with Boost ratio of 2X/3X/4X/5X/6X)
`Bias configuration: 1/6 ~ 1/12 bias.
`Bus width selectable: 1-bit series / 4-bit parallel modes.
`Package: 154-pin COB (Pad Size:80um*80um, Pad Pitch: 95um*95um). (Segment mode)
`Shift clock frequency
   15 MHz (MAX.): VDD = +3.0 to + 4 V
   12 MHz (MAX.): VDD = +2.4 to + 3.0 V
`4-bit parallel / serial input modes are selectable with a mode (P/S) pin
`Automatic transfer function of an enable signal
`Automatic counting function which, in the chip selection mode, causes the internal clock to
  be stopped by automatically counting 88,72,56 ,40,24,8 or 120 bits of input data
`Line latch circuits are reset when XDISPOFF active (Common mode)
`Shift clock frequency: 4 MHz (MAX.)
`Built-in X-bit shift register
`Available in a single mode
`Y1->YX Single mode
   YX->Y1 Single mode
   X=32,48,64,80,96,112,120
`Shift register circuits are reset when XDISPOFF active (16 Levels Gray Display)
`B/W, 4 and 16 gray levels can be displayed by the pulse width modulation.


Pinout

Connection Diagram


Specifications

Item Symbol Rating Condition
Supply Voltage VDD -0.5V ~ 4.0V
Input Voltage VIN -0.5V ~ VDD+0.5V
Output Voltage VO -0.5V ~ VDD+0.5V
Operating Temperature TOP 0 ~ 70
Storage Temperature TST -50 ~ 100



Description

The KD125 is a member of LCD driver IC series developed by King Billion Electronics Co. It's a
120-output common/segment LCD driver IC suitable for driving small/medium scale dot matrix LCD panels, used in PDA or electronic dictionary. The KD125 is good as a segment driver, common driver or common/segment driver, and it can create a low power consuming, high-resolution LCD. The KD125 have eight modes can selected to set common and segment numbers by control register. The KD125 also has built- in analog regulator and DC/DC converter and they can be enabled or disabled to use external LCD power system for larger LCD panel.
