JWMW11RAA, US $ 3.06-3.78 , NKK Switches, JWMW11RAA DataSheet download, circuit diagram from SeekIC.com

See larger image

SeekIC No. : 002630928 Detail

JWMW11RAA: Rocker Switches & Paddle Switches SPST TV5 RATED BLACK CAP PANEL SEAL

JWMW11RAA Data Sheet

US $ 3.06~3.78 / Piece | Get Latest Price

Part Number:: JWMW11RAA
Mfg:: NKK Switches
Supply Ability:: 5000

Price Break

Qty
0~1
1~25
25~50
50~100

Unit Price
$3.78
$3.47
$3.44
$3.06

Processing time
15 Days
15 Days
15 Days
15 Days

View more price & deliveries

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2024/12/21

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

JWMW11RA1A evaluate
US $3.43 - 4.65 / Piece

Rocker Switches & Paddle Switches SPST TV5 RATED BLACK CAP HRZ MRK PNL SEAL
JWMW11RA2A evaluate
US $3.43 - 4.67 / Piece

Rocker Switches & Paddle Switches SPST TV5 RTD BLK CAP &BODY PANL SEAL VERT
JWMW11RA2A/UC evaluate
US $3.53 - 4.38 / Piece

Rocker Switches & Paddle Switches SPST TV5 RTD BLK CAP &BODY PANL SEAL VERT

Product Details

Quick Details

Contact Form :	SPST	Switch Function :	ON - NONE - OFF
Current Rating :	10 A	Voltage Rating AC :	250 V
Voltage Rating DC :	30 V	Termination Style :	Solder Lug
Actuator :	Rocker	Color :	Black
Mounting Style :	Panel	Terminal Seal :	Epoxy
Contact Plating :	Silver	Illumination :	Not Illuminated

Description

Power Rating :
Illumination Color :
Actuator : Rocker
Mounting Style : Panel
Terminal Seal : Epoxy
Contact Plating : Silver
Illumination : Not Illuminated
Voltage Rating AC : 250 V
Termination Style : Solder Lug
Color : Black
Contact Form : SPST
Switch Function : ON - NONE - OFF
Current Rating : 10 A
Voltage Rating DC : 30 V

Parameters:

Technical/Catalog Information	JWMW11RAA
Vendor	NKK Switches of America Inc
Category	Switches
Mounting Type	Panel Mount, Snap-In
Circuit	SPST
Switch Function	On-Off
Contact Rating @ Voltage	10A @ 125VAC
Illumination	Non-Illuminated
Illumination Type, Color	-
Illumination Voltage	-
Termination Style	Quick Connect - .110" (2.8mm)
Panel Cutout Dimensions	25.00mm x 15.40mm
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	JWMW11RAA JWMW11RAA
