Features: • Wide Input Supply Voltage Range- 5.6V to 24V- 4.5V to 5.6V• Three Independently Programmable Output Voltages• Switching Frequency . . . . . . . . . . . . . . . . . . . . . . . 300kHz• Out of Phase PWM Controller Operation- Reduces Required Input Capacitance and ...
ISL6443: Features: • Wide Input Supply Voltage Range- 5.6V to 24V- 4.5V to 5.6V• Three Independently Programmable Output Voltages• Switching Frequency . . . . . . . . . . . . . . . . . . . ...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
DescriptionThe ISL60002 FGA voltage references are very high precision analog voltage references f...
US $2.57 - 3.95 / Piece
Voltage & Current References PREC 3.3V HI OUTPUT FGAVREF 1MV -40 - +1
The ISL6443 is a high-performance, triple-output controller optimized for converting wall adapter, battery or network intermediate bus DC input supplies into the system supply voltages required for a wide variety of applications. Each output is adjustable down to 0.8V. The two PWMs are synchronized 180° out of phase reducing the RMS input current and ripple voltage.
The ISL6443 incorporates several protection features. An adjustable overcurrent protection circuit monitors the output current by sensing the voltage drop across the lower MOSFET. Hiccup mode overcurrent operation protects the DC/DC components from damage during output overload/short circuit conditions. Each PWM has an independent logic-level shutdown input (SD1 and SD2 ).
A single PGOOD signal is issued when soft-start is complete on both PWM controllers and their outputs are within 10% of the set point and the linear regulator output is greater than 75% of its setpoint. Thermal shutdown circuitry turns off the device if the junction temperature exceeds +150.
