Features: • Low Power . . . . . 103mW with 20mA Output at 130MSPS• Adjustable Full Scale Output Current. . . . . 2mA to 20mA• +3.3V Power Supply• 3V LVCMOS Compatible Inputs• Excellent Spurious Free Dynamic Range (71dBc to Nyquist, fS = 130MSPS, fOUT = 10MHz)• U...
ISL5757: Features: • Low Power . . . . . 103mW with 20mA Output at 130MSPS• Adjustable Full Scale Output Current. . . . . 2mA to 20mA• +3.3V Power Supply• 3V LVCMOS Compatible Inputs&...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
DescriptionThe ISL51002 3-channel, 10-bit Analog Front End (AFE) contains all the functionality ne...
DescriptionThe ISL51002 3-channel, 10-bit Analog Front End (AFE) contains all the functionality ne...
The ISL5757 is a 10-bit, current out, CMOS, digital to analog converter. The maximum update rate is at least 60+MSPS and can be powered by a single power supply in the recommended range of +3.0V to +3.6V. It consumes less than 120mW of power when using a +3.3V supply, the maximum 20mA of output current, and the data switching at 210MSPS. The architecture is based on a segmented current source arrangement that reduces glitch by reducing the amount of current switching at any one time. In previous architectures that contained all binary weighted current sources or a binary weighted resistor ladder, the converter might have a substantially larger amount of current turning on and off at certain, worst-case transition points such as midscale and quarter scale transitions. By greatly reducing the amount of current switching at these major transitions, the overall glitch of the converter is dramatically reduced, improving settling time, transient problems, and accuracy.
