Features: • High-speed access time: 12 ns: 3.3V + 10% 15 ns: 2.5V-3.6V• Operating Current: 25mA (typ.)• Stand by Current: 400A(typ.)• TTL and CMOS compatible interface levels• Fully static operation: no clock or refresh required• Three state outputs• Data ...
IS61WV12816BLL: Features: • High-speed access time: 12 ns: 3.3V + 10% 15 ns: 2.5V-3.6V• Operating Current: 25mA (typ.)• Stand by Current: 400A(typ.)• TTL and CMOS compatible interface levels...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
Features: • Internal self-timed write cycle• Individual Byte Write Control and Global ...
Features: • Internal self-timed write cycle• Individual Byte Write Control and Global ...
Features: • Internal self-timed write cycle• Individual Byte Write Control and Global ...
Symbol | Parameter | Value | Unit |
VDD | Power Supply Voltage Relative to GND | 0.5 to 4.0V | V |
VTERM | Terminal Voltage with Respect to GND | 0.5 to VDD + 0.5 | V |
TSTG | Storage Temperature | 65 to + 150 | |
PT | Power Dissipation | 1.0 | W |
The ISSI IS61WV12816BLL and IS64WV12816BLL are high-speed, 2,097,152-bit static RAM organized as 131,072 words by 16 bits. They are fabricated using ISSI's highperformance CMOS technology. This IS61WV12816BLL highly reliable process coupled with innovative circuit design techniques, yields access times as fast as 12 ns with low power consumption.
When CE is HIGH (deselected), the IS61WV12816BLL assumes a standby mode at which the power dissipation can be reduced down with CMOS input levels.
Easy memory expansion is provided by using Chip Enable and Output Enable inputs, CE and OE. The active LOW Write Enable (WE) controls both writing and reading of the memory. A data byte allows Upper Byte (UB) and Lower Byte (LB) access.
The IS61WV12816BLL and IS64WV12816BLL are packaged in the JEDEC standard 44-pin TSOP (Type II) and 48-pinmini BGA (6mm x 8mm).
