IRUD400CW60

Product : Ultra Fast Recovery Rectifiers
Reverse Voltage : 600 V
Packaging : Tube
Configuration : Dual Common Cathode
Forward Continuous Current : 330 A
Max Surge Current : 1200 A
Mounting Style : Screw
Package / Case : TO-244
Recovery Time : 90 ns
Forward Voltage Drop : 2.3 V at 400 A
Reverse Current IR : 1380 uA


Features:

• Ultrafast Recovery
• Lead-Free


Application

These diodes are optimized to reduce losses and EMI/ RFI in high frequency power conditioning systems. The softness of the recovery eliminates the need for a snubber in most applications. These devices are ideally suited for HF welding, power converters and other applications where switching losses are significant portion of the total losses.

Specifications

Parameters (*)			Max	Units
VR	Cathode-to-Anode Voltage		600	V
IF(AV)	Continuous Forward Current	@ TC = 25	330	A
		@ TC = 85	230
		@ TC = 97	200
IFSM	Single Pulse Forward Current		1200
PD	Maximum Power Dissipation	@ TC = 25	660	W
		@ TC = 97	280

Description

These diodes IRUD400CW60 are optimized to reduce losses and EMI/ RFI in high frequency power conditioning systems. The softness of the recovery eliminates the need for a snubber in most applications. These devices IRUD400CW60 are ideally suited for HF welding, power converters and other applications where switching losses are significant portion of the total losses.
