IRLS4030PBF

MOSFET

product image

IRLS4030PBF Picture
See larger image
SeekIC No. : 00153261 Detail

IRLS4030PBF: MOSFET

IRLS4030PBF Data Sheet

floor Price/Ceiling Price

US $ 1.74~3.55 / Piece | Get Latest Price
Part Number:
IRLS4030PBF
Mfg:
International Rectifier
Supply Ability:
5000

Price Break

  • Qty
  • 0~1
  • 1~25
  • 25~100
  • 100~250
  • Unit Price
  • $3.55
  • $2.43
  • $1.76
  • $1.74
  • Processing time
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/24

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Transistor Polarity : N-Channel Drain-Source Breakdown Voltage : 100 V
Gate-Source Breakdown Voltage : 16 V Continuous Drain Current : 180 A
Resistance Drain-Source RDS (on) : 4.5 mOhms Mounting Style : SMD/SMT
Package / Case : D2PAK Packaging : Tube

Description

Configuration :
Maximum Operating Temperature :
Transistor Polarity : N-Channel
Mounting Style : SMD/SMT
Drain-Source Breakdown Voltage : 100 V
Package / Case : D2PAK
Packaging : Tube
Gate-Source Breakdown Voltage : 16 V
Resistance Drain-Source RDS (on) : 4.5 mOhms
Continuous Drain Current : 180 A


Parameters:

Technical/Catalog InformationIRLS4030PBF
VendorInternational Rectifier
CategoryDiscrete Semiconductor Products
Mounting TypeSurface Mount
FET PolarityN-Channel
Drain to Source Voltage (Vdss)100V
Current - Continuous Drain (Id) @ 25° C180A
Rds On (Max) @ Id, Vgs4.3 mOhm @ 110A, 10V
Input Capacitance (Ciss) @ Vds 11360pF @ 50V
Power - Max370W
PackagingTube
Gate Charge (Qg) @ Vgs130nC @ 4.5V
Package / CaseD²Pak, TO-263 (2 leads + tab)
FET FeatureLogic Level Gate
Drawing Number*
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names IRLS4030PBF
IRLS4030PBF
