IR3221

Features: • Over temperature shutdown• Over current shutdown• nrush current limited by Soft-Start sequence• E.S.D protection• Sleep mode for direct battery connection• Braking / non-braking operation• Internal switching oscillator• Direct interface f...

product image

IR3221 Picture
See larger image
SeekIC No. : 004376197 Detail

IR3221: Features: • Over temperature shutdown• Over current shutdown• nrush current limited by Soft-Start sequence• E.S.D protection• Sleep mode for direct battery connection&#...

IR3221 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
IR3221
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/5/31

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

• Over temperature shutdown
• Over current shutdown
• nrush current limited by Soft-Start sequence
• E.S.D protection
• Sleep mode for direct battery connection
• Braking / non-braking operation
• Internal switching oscillator
• Direct interface for End switches


Pinout

Connection Diagram


Specifications

Symbol Parameter Min. Max. Units
Vm1 (2) Maximum M1 (M2) voltage (active clamp) Vcc-37 Vcc+0.3 V
Vin1 (2) Maximum IN 1 (IN 2) voltage -0.3 5.5 V
Iin1 (2) Maximum IN1 (IN 2) current -1 10 mA
Vg1 (2) Maximum Gate 1 ( Gate 2 ) voltage -0.3 7.5 V
Vss Maximum SS voltage -0.3 5.5 V
Isd cont. Diode max. permanent current(Rth=50/W) - 4 A
Isd pulsed Diode max. pulsed current - 45 A
ESD 1 Electrostatic discharge ( human body model C=100pF, R=1500Ω) - 4 kV
ESD 2 Electrostatic discharge ( machine model C=200pF, R=0Ω - 0.5 kV
PD Maximum power dissipation ( Rth = 50/W ) - 2.5 W
TJ max. Max. storage & operating junction temperature -40 +150
T lead Lead temperature ( soldering 10 s ) - 300



Description

The IR3221 is a Fully Protected Dual High Side Switch I.C. With two additional Low Side switches (IRL1404), the IR3221 drives and controls the whole H bridge topology. It provides shoot-through protection for each leg, H bridge logic control, soft-start sequence and over-current /over-temp. protections. The signals IN1 and IN2 select the operation modes and the PWM Soft-Start sequence cycles the corresponding active low side switch in order to limit the motor inrush current. By using the recommended part number and the proper cooling, the inner High Side IPS protects the whole H-bridge function. The Soft-Start sequence is programmed by an RC time constant and reset itself automatically.
