IR2113L6

Features: Floating channel designed for bootstrap operation Fully operational to +600V Tolerant to negative transient voltage dV/dt immune Gate drive supply range from 10 to 20V Undervoltage lockout for both channels Separate logic supply range from 5 to 20V Logic and power ground ±5V offset CMOS ...

product image

IR2113L6 Picture
See larger image
SeekIC No. : 004376077 Detail

IR2113L6: Features: Floating channel designed for bootstrap operation Fully operational to +600V Tolerant to negative transient voltage dV/dt immune Gate drive supply range from 10 to 20V Undervoltage lockout...

IR2113L6 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
IR2113L6
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/24

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

Floating channel designed for bootstrap operation Fully operational to +600V Tolerant to negative transient voltage dV/dt immune
Gate drive supply range from 10 to 20V
Undervoltage lockout for both channels
Separate logic supply range from 5 to 20V Logic and power ground ±5V offset
CMOS Schmitt-triggered inputs with pull-down
Cycle by cycle edge-triggered shutdown logic
Matched propagation delay for both channels
Outputs in phase with inputs




Specifications

Symbol
 Parameter
Min.
Max.
Units
VB
 High Side Floating Supply Absolute Voltage
0.5
VS + 20
V
VS
 High Side Floating Supply Offset Voltage
-
600
VHO
 High Side Output Voltage
VS -0.5
VB + 0.5
VCC
 Low Side Fixed Supply Voltage
-0.5
20
VLO
 Low Side Output Voltage
-0.5
VCC + 0.5
VDD
 Logic Supply Voltage
-0.5
VSS + 20
VSS
 Logic Supply Offset Voltage
VCC - 20
VCC + 0.5
VIN
 Logic Input Voltage (HIN, LIN & SD)
VSS - 0.5
VDD + 0.5
dVS/dt
 Allowable Offset Supply Voltage Transient (Fig. 16)
-
50
V/ns
PD
 Package Power Dissipation @ TA = 25°C (Fig. 19)
-
1.6
W
RthJA
 Thermal Resistance, Junction to Ambient
-
75
°C/W
Tj
 Junction Temperature
-55
125
°C
TS
 Storage Temperature
-55
150
TL
 Package Mounting Surface Temperature
-

300

 Weight
1.5 (typical)
g





Description

The IR2113L6 is a high voltage, high speed power MOSFET and IGBT driver with independent high and low side refer-enced output channels. Proprietary HVIC and latch immune CMOS technologies enable ruggedized monolithic construc-tion. Logic inputs are compatible with standard CMOS or LSTTL outputs. The output drivers feature a high pulse current buffer stage designed for minimum driver cross-con-duction. Propagation delays are matched to simplify use in high frequency applications. The floating channel can be used to drive an N-channel power MOSFET or IGBT in the high side configuration which operates up to 600 volts.
