IR2106STRPBF

Power Driver ICs Hi&Lw Sd Drvr Soft Trn On Noninvert

product image

IR2106STRPBF Picture
See larger image
SeekIC No. : 00536831 Detail

IR2106STRPBF: Power Driver ICs Hi&Lw Sd Drvr Soft Trn On Noninvert

IR2106STRPBF Data Sheet

floor Price/Ceiling Price

US $ .74~1.59 / Piece | Get Latest Price
Part Number:
IR2106STRPBF
Mfg:
International Rectifier
Supply Ability:
5000

Price Break

  • Qty
  • 0~1
  • 1~25
  • 25~100
  • 100~250
  • Unit Price
  • $1.59
  • $.94
  • $.74
  • $.74
  • Processing time
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/14

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Type : High and Low Side Rise Time : 220 ns
Fall Time : 80 ns Supply Voltage - Max : 20 V
Supply Voltage - Min : 10 V Maximum Power Dissipation : 625 mW
Maximum Operating Temperature : + 125 C Mounting Style : SMD/SMT
Package / Case : SOIC-8 Packaging : Reel

Description

Product :
Supply Current :
Mounting Style : SMD/SMT
Packaging : Reel
Maximum Operating Temperature : + 125 C
Package / Case : SOIC-8
Supply Voltage - Max : 20 V
Supply Voltage - Min : 10 V
Fall Time : 80 ns
Maximum Power Dissipation : 625 mW
Type : High and Low Side
Rise Time : 220 ns


Parameters:

Technical/Catalog InformationIR2106STRPBF
VendorInternational Rectifier (VA)
CategoryIntegrated Circuits (ICs)
ConfigurationHigh and Low Side, Independent
Voltage - Supply10 V ~ 20 V
Current - Peak200mA
Delay Time180ns
Package / Case8-SOIC (3.9mm Width)
PackagingCut Tape (CT)
Number of Outputs2
Input TypeNon-Inverting
Number of Configurations1
Operating Temperature-40°C ~ 125°C
High Side Voltage - Max (Bootstrap)600V
Drawing Number*
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names IR2106STRPBF
IR2106STRPBF
IR2106SPBFCT ND
IR2106SPBFCTND
IR2106SPBFCT
