IR130CSP

Features: ·Ultra Low VF per Footprint Area·Low Thermal Resistance·One-fifth Footprint of SMA·Super Low Profile (<.8mm)·Available Tested on Tape & ReelSpecifications Parameters Values Units Conditions IF(AV) Max. Average Forward (Per Leg) Current (Per Device) 1 ...

product image

IR130CSP Picture
See larger image
SeekIC No. : 004376014 Detail

IR130CSP: Features: ·Ultra Low VF per Footprint Area·Low Thermal Resistance·One-fifth Footprint of SMA·Super Low Profile (<.8mm)·Available Tested on Tape & ReelSpecifications Parameters Va...

IR130CSP Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
IR130CSP
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/23

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

·Ultra Low VF per Footprint Area
·Low Thermal Resistance
·One-fifth Footprint of SMA
·Super Low Profile (<.8mm)
·Available Tested on Tape & Reel


Specifications

Parameters
Values
Units
Conditions
IF(AV)
 Max. Average Forward (Per Leg)
Current (Per Device)
1
A
 50% duty cycle @ TC = 113 , rectangular wave form
IFSM
 Max.Peak One Cycle Non -Repetitive
Surge Current (Per Leg)
220
21
A
 5s Sine or 3s Rect. pulse Following any rated load
condition and with rated
VRRM applied
10ms Sine or 6ms Rect. pulse
EAS
Non -Repetitive Avalanche Energy
(Per Leg)
10
mJ
 TJ = 25 IAS = 3Amps, L = 4.40mH
IAR
 Repetitive Avalanche Current Current
(Per Leg)
2
A
 decaying linearty to zero in 1 sec
Frequency limited by TJ max. VA = 1.5 x VR typical



Description

True chip-scale packaging of the IR130CSP is available from International Rectifier. The IR130CPS surface-mount Schottky rectifier has been designed for applications requiring low forward drop and very small foot prints on PC boards.Typical applications are in disk drives, switching power supplies, converters, free-wheeling diodes, battery charging, and reverse battery protection.

·Small foot print, surface mountable
·Low forward voltage drop
·High frequency operation
·Guard ring for enhanced ruggedness and long term reliability

The FlipkyTM package of the IR130CSP, is one-fifth the footprint of a comparable SMA package and has a profile of less then.8mm. Combined with the low thermal resistance of the die level device, this makes the FlipkyTM the best device for application where printed circuit board space is at a premium and in extremely thin application environments such as battery packs, cell phones and PCMCIA cards.
