Product Details

Description



Features:

• Low power consumption
• Wide common-mode and differential voltage range
• Low input bias and offset currents
• Low noise en=18 nV/Hz (typ)
• Output short-circuit protection
• High input impedance J-FET input stage
• Low harmonic distortion: 0.01% (typ)
• Internal frequency compensation
• Latch up free operation
• High slew rate: 13 V/s (typ)


Pinout

Connection Diagram


Specifications

Symbol Parameter IL062 Units
VCC Supply Voltage (note 1) ±18 V
Vi Input Voltage (note 3) ±15 V
Vid Differential Input Voltage (note 2) ±30 V
Ptot Power Dissipation 680 mW
  Output Short-Circuit Duration (Note 4) Infinite
Toper Operating Free-Air Temperature Range -40 to +85 °C
Tstg Storage Temperature Range -65 to +150 °C



Description

The IL072 are high speed JFET input dual operational amplifiers incorporating well matched, high voltage JFET and bipolar transistors in a monolithic integrated circuit.

The IL072 feature high slew rates, low input bias and offset current, and low offset voltage temperature coefficient.
