IDTQS74FCT2827AT

• CMOS power levels: <7.5mW static
• Undershoot clamp diodes on all outputs
• True TTL input and output compatibility
• Ground bounce controlled outputs
• Reduced output swing of 0 to 3.5V
• Built-in 25Ω series resistor outputs reduce reflection and othersystem noise
• A,B, and C speed grades with 4.4ns tPD for C
• IOL = 12mA
• Available in SOIC and QSOP packages

The IDTQS74FCT2827AT is a 10-bit buffer with 3-state outputs and a25Ω resistor, useful for driving transmission lines and reducing systemnoise. The 2827T series parts can replace the 827T series to reduce noisein an existing design. All inputs have clamp diodes for undershoot noisesuppression. All outputs have ground bounce suppression. Outputs will notload an active bus when Vcc is removed from the device.
