IDTQS3162233

NOTES:
1. Stresses greater than those listed under ABSOLUTE MAXIMUM RATINGS may cause permanent damage to the device. This is a stress rating only and functional operation of the device at these or any other conditions above those indicated in the operational sections of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect reliability.
2. VCC terminals.
3. All terminals except VCC .

The QS3162233 is a 32-bit to 16-bit high-speed CMOS, TTL-compatible switch which can multiplex or demultiplex data. IDTQS3162233 can be used for memory interleaving where two memory banks need to be addressed simultaniously. IDTQS3162233 can also be used as two 16-bit to 8-bit multiplexers or as one 32-bit to 16- bit multiplexer. SELn inputs control the data flow. TESTn inputs control either one or two ports connection. The QS3162233 adds an internal 25 series termination resistor to each switch to reduce reflection noise in high-speed applications.

Mux/Demux devices IDTQS3162233 provide an order of magnitude faster speed than equivalent logic devices.

The QS3162233 is characterized for operation at -40°C to +85°C.
