Features: • 1,024 x 1,024 channel non-blocking switching at 8.192 Mb/s• Per-channel variable or constant throughput delay• Automatic identification of ST-BUS®/GCI interfaces• Accepts 8 Serial Data Streams of 8.192 Mb/s• Automatic frame offset delay measurementR...
IDT72V70810: Features: • 1,024 x 1,024 channel non-blocking switching at 8.192 Mb/s• Per-channel variable or constant throughput delay• Automatic identification of ST-BUS®/GCI interfaces...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
Symbol | Parameter | Min. | Max. | Unit |
VCC | Supply Voltage | -0.3 | 5.0 | V |
Vi | Voltage on Digital Inputs | GND -0.3 | 5.5 | V |
IO | Current at Digital Outputs | 20 | mA | |
TS | Storage Temperature | -65 | +125 | °C |
PD | Package Power Dissapation | | 1 | W |
The IDT72V70810 is a non-blocking digital switch that has a capacity of 1,024 x 1,024 channels at a serial bit rate of 8.192 Mb/s. Some of the main features are: programmable stream and channel control, Processor Mode, input offset delay and high-impedance output control.
Per-stream input delay control of the IDT72V70810 is provided for managing large multi-chip switches that transport both voice channel and concatenated data channels. In addition, input streams can be individually calibrated for input frame offset.
