Features: • Memory storage capacity:IDT723623 256 x 36IDT723633 512 x 36IDT723643 1,024 x 36• Clocked FIFO buffering data from Port A to Port B• Clock frequencies up to 83 MHz (8 ns access time)• IDT Standard timing (using EF and FF) or First Word Fall Through Timing (us...
IDT723643: Features: • Memory storage capacity:IDT723623 256 x 36IDT723633 512 x 36IDT723643 1,024 x 36• Clocked FIFO buffering data from Port A to Port B• Clock frequencies up to 83 MHz (...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
CHARACTERISTIC |
SYMBOL |
Commercial |
UNIT |
Supply Voltage |
VCC |
0.5 to 7 |
V |
Input Voltage Range |
VI(2) |
0.5 to VCC+0.5 |
V |
Output Voltage Range |
VO(2) |
0.5 to VCC+0.5 |
V |
Input Clamp Current (VI < 0 or VI > VCC) |
IIK |
±20 |
mA |
Output Clamp Current (VO = < 0 or VO > VCC) |
IOK |
±50 |
mA |
Continuous Output Current (VO = 0 to VCC) |
IOUT |
±50 |
mA |
Continuous Current Through VCC or GND |
ICC |
±400 |
mA |
Storage Temperature Range |
Tstg |
-65to150 |
NOTES:
1. Stresses beyond those listed under "Absolute Maximum Ratings" may cause permanent damage to the device. These are stress ratings only and functional operation of the device at these or any other conditions beyond those indicated under "recommended operating conditions" is not implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
2. The input and output voltage ratings may be exceeded provided the input and output current ratings are observed.
The IDT723643 are monolithic, high-speed, low-power, CMOS unidirectional Synchronous (clocked) FIFO memories which support clock frequencies up to 83 MHz and have read access times as fast as 8 ns.
