IDT71V416VL

NOTE:
1. Stresses greater than those listed under ABSOLUTE MAXIMUM RATINGS may cause permanent damage to the device. This is a stress rating only and functional operation of the device at these or any other conditions above those indicated in the operational sections of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect reliability.

The IDT71V416VL is a 4,194,304-bit high-speed Static RAM organized as 256K x 16. It is fabricated using IDT's high-perfomance, high-reliability
CMOS technology. This state-of-the-art technology, combined with inno vative circuit design techniques, provides a cost-effective solution for high-
speed memory needs.

The IDT71V416VL has an output enable pin which operates as fast as 5ns, with address access times as fast as 10ns. All bidirectional inputs and
outputs of the IDT71V416 are LVTTL-compatible and operation is from a single 3.3V supply. Fully static asynchronous circuitry is used, requiring
no clocks or refresh for operation.

The IDT71V416VL is packaged in a 44-pin, 400 mil Plastic SOJ and a 44-pin, 400 mil TSOP Type II package and a 48 ball grid array, 9mm x 9mm package.
