IDT49FCT3805E

Features: • Advanced CMOS Technology• Guaranteed low skew < 200ps (max.)• Very low propagation delay < 2.5ns (max)• Very low duty cycle distortion < 270ps (max)• Very low CMOS power levels• Operating frequency up to 166MHz• TTL compatible inputs a...

product image

IDT49FCT3805E Picture
See larger image
SeekIC No. : 004371689 Detail

IDT49FCT3805E: Features: • Advanced CMOS Technology• Guaranteed low skew < 200ps (max.)• Very low propagation delay < 2.5ns (max)• Very low duty cycle distortion < 270ps (max)̶...

IDT49FCT3805E Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
IDT49FCT3805E
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/2/15

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:


• Advanced CMOS Technology
• Guaranteed low skew < 200ps (max.)
• Very low propagation delay < 2.5ns (max)
• Very low duty cycle distortion < 270ps (max)
• Very low CMOS power levels
• Operating frequency up to 166MHz
• TTL compatible inputs and outputs
• Inputs can be driven from 3.3V or 5V components
• Two independent output banks with 3-state control
• 1:5 fanout per bank
• "Heartbeat" monitor output
• VCC = 3.3V ± 0.3V
• Available in SSOP and QSOP packages


Pinout

Connection Diagram


Specifications



Symbol
Rating
Commercial
& Industrial
Unit
VTERM
Input Power Supply Voltage
-0.5 to +4.6
V
VTERM
Input Voltage
0.5 to +5.5
V
VTER(2)
Output Voltage
0.5 to VCC+0.5
°C
TSTG
Storage Temperature
65 to +165
°C
IOUT
Junction Temperature
150
mA
NOTE:
1. Stresses greater than those listed under ABSOLUTE MAXIMUM RATINGS may cause
permanent damage to the device. This is a stress rating only and functional operation
of the device at these or any other conditions above those indicated in the operational
sections of this specification is not implied. Exposure to absolute maximum rating
conditions for extended periods may affect reliabil


Description

The IDT49FCT3805E is a 3.3 volt clock driver built using advanced CMOS technology. The device consists of two banks of drivers, each with a 1:5 fanout and its own output enable control. The device has a "heartbeat" monitor for diagnostics and PLL driving. The MON output is identical to all other outputs and complies with the output specifications in this document.

The IDT49FCT3805E offers low capacitance inputs. The FCT3805 is designed for high speed clock distribution where signal quality and skew are critical. The IDT49FCT3805E also allows single point-to-point transmission line driving in applications such as address distribution, where one signal must be distributed to multiple recievers with low skew and high signal quality.
