ICS9FG104

Features: • Generates common CPU frequencies from 14.318 MHz or 25 MHz• Crystal or reference input• 4 - 0.7V current-mode differential output pairs• Supports Serial-ATA at 100 MHz• Two spread spectrum modes: 0 to -0.5 downspread and +/-0.25% centerspread• Unused...

product image

ICS9FG104 Picture
See larger image
SeekIC No. : 004371355 Detail

ICS9FG104: Features: • Generates common CPU frequencies from 14.318 MHz or 25 MHz• Crystal or reference input• 4 - 0.7V current-mode differential output pairs• Supports Serial-ATA at 10...

ICS9FG104 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
ICS9FG104
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/21

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

• Generates common CPU frequencies from 14.318 MHz or 25 MHz
• Crystal or reference input
• 4 - 0.7V current-mode differential output pairs
• Supports Serial-ATA at 100 MHz
• Two spread spectrum modes: 0 to -0.5 downspread and +/-0.25% centerspread
• Unused inputs may be disabled in either driven or Hi-Z state for power management.
• M/N Programming


Application

Frequency Timing Generator for Differential CPU & SATA clocks


Pinout

Connection Diagram


Specifications

Symbol Parameter Min Max Units
VDD_A 3.3V Core Supply Voltage   VDD + 0.5V V
VDD_In 3.3V Logic Input Supply Voltage GND - 0.5 VDD + 0.5V V
Ts Storage Temperature -65 150
Tambient Ambient Operating Temp 0 70
Tcase Case Temperature   115
ESD prot Input ESD protection
human body model		 2000   V



Description

The ICS9FG104 is a Frequency Timing Generator that provides 4 differential output pairs that are compliant to the Intel CK410 specification. It also provides support for PCI-Express and SATA. The part synthesizes several output frequencies from either a 14.31818 Mhz crystal or a 25 MHz crystal. The device can also be driven by a reference input clock instead of a crystal. It provides outputs with cycle-to-cycle jitter of less than 50 ps and output-to-output skew of less than 35 ps.

The ICS9FG104 also provides a copy of the reference clock. Frequency selection can be accomplished via strap pins or SMBus control.
