Product Details

Description



Features:

• Provides standard frequencies and additional 5% and 10% over-clocked frequencies
• Supports spread spectrum modulation: No spread, Center Spread (±0.35%, ±0.5%, or ±0.75%), or Down Spread (-0.5%, -1.0%, or -1.5%)
• Offers adjustable PCI early clock via latch inputs
• Selectable 1X or 2X strength for REF via I2C interface
• Efficient power management scheme through PD#, CPU_STOP# and PCI_STOP#.
• Uses external 14.318MHz crystal
• Stop clocks and functional control available through I2C interface.


Pinout

Connection Diagram


Specifications

Supply Voltage . . . . . . . . . . . . . . . . . . . . . . . . . 5.5 V
Logic Inputs . . . . . . . . .    GND 0.5 V to VDD +0.5 V
Ambient Operating Temperature . . .  0°C to +90°C
Case Temperature . . . . . . . . . . . . . . . . . . . . .115°C
Storage Temperature . . . . . . . . .65°C to +150°C
Stresses above those listed under Absolute Maximum Ratings may cause permanent damage to the device. These ratings are stress specifications only and functional operation of the device at these or any other conditions above those listed in the operational sections of the specifications is not implied. Exposure to absolute maximum rating conditions for extended periods may affect product reliability.
