ICS9219

Supply voltage range, V_DD or VDDT (see Note 1) . . . . . . . . . . . . . . . . . . . . . . . . . . -0.5 V to 4 V
Input voltage range,V_I, at any input terminal . . . . . . . . . . . . . . . . . . . . . .-0.5 V to V _DD + 0.5 V
Output voltage range, V_O, at any output terminal (BUSCLKT/C) . . . . . . . .-0.5 V to V _DD + 0.5 V
ESD rating (MIL-STD 883C, Method 3015) . . . . . . . . . . . . . . . . . .> 2 kV, Machine Model >200 V
Operating free-air temperature range, T_A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0°C to 85°C
Storage temperature range, T_stg . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -65°C to 150°C
Stresses beyond those listed under absolute maximum ratings may cause permanent damage to the device. These are stress ratings only, and functional operation of the device at these or any other conditions beyond those indicated under recommended operating conditions is not implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
NOTE 1: All voltage values are with respect to the GND terminals.

ICS9219 is a High-speed clock generator providing 400 or 533 MHz differential clock source for direct Rambus memory system. ICS9219 takes a crystal as an input reference source, and produces the differential output clock required for the Rambus channel. ICS9219 provides a solution for a broad range of Direct Rambus memory applications. ICS9219 can be used in single or dual Rambus channels. An additional LVCMOS output, which provides a reference clock at the crystal frequency for the other system blocks is also included.
