ICS91719

• ICS91719 is a Spread Spectrum Clock targeted for Mobile PC and LCD panel applications. Generates an EMI optimized clock signal (EMI peak reduction of 7-14 dB on 3rd-19th harmonics) through use of Spread Spectrum techniques.

• ICS91719 focuses on the lower input frequency range of 14.318 to 80.00 MHz with a spread modulation of 20kHz to 40kHz.

Supply Voltage . . . . . . . . . . . . . . . . . . . . .. . .  . . . . . . 3.3 V
Voltage on any pin with respect to GND .  . .. -0.5 to +7.0 V
Storage Temperature . . . . . . . . . . . . . . . . 55 to +125
Operating Temperature . . . . . . . . . . . . . . . . . . 0 to +85
Ambient Operating Temperature under Bias. -55 to +125
Power Dissipation . . . . . . . . . . . . . . . . . . . . .. . . . . . . 0.5 W

Stresses above those listed under Absolute Maximum Ratings may cause permanent damage to the device. These ratings are stress specifications only and functional operation of the device at these or any other conditions above those listed in the operational sections of the specifications is not implied. Exposure to absolute maximum rating conditions for extended periods may affect product reliability.
