ICS91718

• ICS91718 is a Spread Spectrum Clock targeted for Mobile PC and LCD panel applications. Generates an EMI optimized clock signal (EMI peak reduction of 7-14 dB on 3rd-19th harmonics) through use of Spread Spectrum techniques.
• ICS91718 operates with input frequencies at 14.318 - 80 MHz.
• Spread modulation frequency range is 20kHz to 40kHz.
• Spread percentage/type programming through I²C.

Supply Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  3.3 V
Voltage on any pin with respect to GND . . . . . . -0.5 to +7.0 V
Storage Temperature . . . . . . . . . . . . . . . .55°C to +125°C
Operating Temperature . . . . . . . . . . . . . . . . .  0°C to +85°C
Ambient Operating Temperature under Bias . -55 to +125 °C
Power Dissipation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.5 W
Stresses above those listed under Absolute Maximum Ratings may cause permanent damage to the device. These ratings are stress specifications only and functional operation of the device at these or any other conditions above those listed in the operational sections of the specifications is not implied. Exposure to absolute maximum rating conditions for extended periods may affect product reliability.
