ICS308

Features: • Packaged in 20-pin SSOP (QSOP)• Operating voltage of 3.3 V• Highly accurate frequency generation• M/N Multiplier PLL: M = 1..2048, N = 1..1024• Serially programmable: user determines the output frequency via a 3-wire interface• Eliminates need for cu...

product image

ICS308 Picture
See larger image
SeekIC No. : 004370760 Detail

ICS308: Features: • Packaged in 20-pin SSOP (QSOP)• Operating voltage of 3.3 V• Highly accurate frequency generation• M/N Multiplier PLL: M = 1..2048, N = 1..1024• Serially pro...

ICS308 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
ICS308
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/1/2

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

• Packaged in 20-pin SSOP (QSOP)
• Operating voltage of 3.3 V
• Highly accurate frequency generation
• M/N Multiplier PLL: M = 1..2048, N = 1..1024
• Serially programmable: user determines the output frequency via a 3-wire interface
• Eliminates need for custom quartz oscillators
• Input crystal frequency of 5 - 27 MHz
• Optional programmable on-chip crystal capacitors
• Output clock frequencies up to 200 MHz
• Reference clock output
• Power down tri-state mode
• Very low jitter


Pinout

Connection Diagram


Specifications

Parameter Conditions
Minimum
Typical
Maximum
Units
Supply Voltage, VDD Referenced to GND
7
V
Inputs Referenced to GND
-0.5
VDD+0.5
V
Clock Output Referenced to GND
-0.5
VDD+0.5
V
Soldering Temperature Max of 10 seconds
260
Storage temperature
-65
150



Description

The ICS308 is a versatile serially programmable, quad PLL clock source. The ICS308 can generate any frequency from 250 kHz to 200 MHz, and up to 6 different output frequencies simultaneously. The outputs can be reprogrammed on the fly, and will lock to a new frequency in 10 ms or less. Smooth transitions (in which the clock duty cycle remains roughly 50%) are guaranteed if the output divider is not changed.

The ICS308 includes a PDTS pin which tri-states the output clocks and powers down the entire chip.

The ICS308 default for non-programmed start-up are buffered reference clock outputs on all clock output pins.
