ICM200E

The ICM200E (formerly ICM109W+) 2 megapixel (UXGA) digital color CMOS image sensor incorporates IC Media's industry-leading, wide acceptance angle pixel architecture, which is optimized for very low profile camera module applications with near CCD-quality color reproduction and low light sensitivity. The ICM200E image sensor has an UXGA-format RGB color pixel array (1600Hx1200V) capable of operating at up to 20 frames per second (fps) at full UXGA resolution and at progressively higher frame rates operating at sub-sampled SVGA and QSVGA resolutions.

The ICM200E image sensor's registers are programmed through an efficient, two-wire serial control interface (SIF) enabling flexible control of the sensor's operating modes. It outputs 10-bit raw RGB pixel samples synchronized to the associated pixel clock (PCLK) as well as vertical and horizontal synchronization signals (VSYNC/HSYNC). Few required external passive devices and low power consumption make the ICM200E image sensor ideally suited for compact form factor, battery-operated mobile consumer devices.
