HWD2108

If Military/Aerospace specified devices are required, please contact the CSMSC Semiconductor Sales Office/ Distributors for availability and specifications.
Supply Voltage                                             6.0V
Storage Temperature           −65°C to +150°C
Input Voltage                      −0.3V to V_DD + 0.3V
Power Dissipation (Note 4)         Internally limited
ESD Susceptibility (Note 5)                       3500V
ESD Susceptibility (Note 6)                         250V
Junction Temperature                              150°C
Soldering Information (Note 1)
    Small Outline Package
      Vapor Phase (60 seconds)                215°C
      Infrared (15 seconds)                       220°C
Thermal Resistance
_JC (MSOP)                                          56°C/W
_JA (MSOP)                                        210°C/W
_JC (SOP)                                             35°C/W
_JA (SOP)                                           170°C/W
_JC (LLP)                                              15°C/W
_JA (LLP)                              117°C/W (Note 9)
_JA (LLP)                            150°C/W (Note 10)

The HWD2108 is a dual audio power amplifier capable of delivering 105mWper channel of continuous average power into a 16W load with 0.1%(THD+N) from a 5V power supply. audio power amplifiers were designed specifically to provide high quality output power with a minimal amount of external components using surface mount packaging. Since the HWD2108 does not require bootstrap capacitors or snubber networks, it is optimally suited for low-power portable systems.

The unity-gain stable HWD2108 can be configured by external gain-setting resistors.
