HV7161SPA2

1.3Mega pixel CIS HV7161SPA2 is a highly integrated single chip CMOS color image sensor implemented by proprietary MagnaChip 0.18um CMOS sensor process realizing high sensitivity and wide dynamic range. Total active pixel array is 1.3Mega size. Each active pixel composed of 4 transistors has a micro-lens to enhance sensitivity, and converts photon energy to analog pixel voltage. On-chip 11bit Analog to Digital Converter (ADC) digitizes analog pixel voltage, and on-chip Correlated Double Sampling (CDS) scheme reduces Fixed Pattern Noise (FPN) dramatically. General image processing functions are implemented to diversify its applications, and various output formats are supported for the sensor HV7161SPA2 to easily interface with different video codec chips. The integration of sensor function and image processing functions make 1.3Mega pixel CIS especially very suitable for mobile imaging systems such as digital still camera, PC input camera and IMT-2000 phone's video part that requires very low power and system compactness.
