Features: ` Operating voltage VCC Read: 2.0V~5.5V Write: 2.4V~5.5V` Low power consumption Operating: 5mA max. Standby: 10mA max.` User selectable internal organization 4K(HT93LC66): 512´8 or 256´16` 3-wire Serial Interface` Write cycle time: 5ms max.` Automatic erase-before-write opera...
HT93LC66: Features: ` Operating voltage VCC Read: 2.0V~5.5V Write: 2.4V~5.5V` Low power consumption Operating: 5mA max. Standby: 10mA max.` User selectable internal organization 4K(HT93LC66): 512´8 or 2...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
Operation Temperature (Commercial) ......................................0°C to 70°C
Applied VCC Voltage with Respect to VSS .................................0.3V to 6.0V
Applied Voltage on any Pin with Respect to VSS............VSS0.3V to VCC+0.3V
Supply READ Voltage ......................................................................2V to 5.5V
Note: These are stress ratings only. Stresses exceeding the range specified under "Absolute Maximum Ratings" may cause substantial damage to the device. Functional operation of this device at other conditions beyond those listed in the specification is not implied and prolonged exposure to extreme conditions may affect device reliability
The HT93LC66 is a 4K-bit low voltage nonvolatile, serial electrically erasable programmable read only memory device using the CMOS floating gate process. Its 4096 bits of memory are organized into 256 words of 16 bits each when the ORG pin is connected to VCC or organized into 512 words of 8 bits each when it is tied to VSS. The device HT93LC66 is optimized for use in many industrial and commercial applications where low power and low voltage operation are essential. By popular microcontroller, the versatile serial interface including chip select (CS), serial clock (SK), data input (DI) and data output (DO) can be easily controlled.
