HT600

Supply Voltage............................-0.3V to 13V
Input Voltage .................V_SS-0.3 to V_DD+0.3V
Storage Temperature............... -50 to 125
Operating Temperature ..............-20 to 75

Note: These are stress ratings only. Stresses exceeding the range specified under "Absolute Maximum Ratings" may cause substantial damage to the device. Functional operation of this device at other conditions beyond those listed in the specification is not implied and prolonged exposure to extreme conditions may affect device reliability.

The 3¹⁸ encoders HT600 are a series of CMOS LSIs for remote control system applications. They are capable of encoding 18 bits of information which consists of N address bits and 18-N data bits. Each address/data input is externally trinary programmable if bonded out. HT600 is otherwise set floating internally. Various packages of the 3¹⁸ encoders offer flexible combinations of programmable address/data to meet various application needs. The programmable address/data is transmitted together with the header bits via an RF or an infrared transmission medium upon receipt of a trigger signal. The capability to select a TE trigger type or a DATA trigger type further enhances the application flexibility of the 3¹⁸ series of encoders.
