HS-2400RH

HS-2400RH is a four-channel programmable amplifier providing a level of versatility unsurpassed by any other monolithic operational amplifier. Versatility is achieved by employing four input amplifier channels, any one (or none) of which may be electronically selected and connected to a single output stage through DTL/TTL compatible address inputs. The device HS-2400RH formed by the output and the selected pair of inputs is an op amp which delivers excellent slew rate, gain bandwidth and power bandwidth performance. Other advantageous features for these dielectrically isolated amplifiers include high voltage gain and input impedance coupled with low input offset voltage and offset current. External compensation is not required on this device at closed loop gains greater than 10.

Each channel of the HS-2400RH can be controlled and operated with suitable feedback networks in any of the standard op amp configurations. This specialization makes these amplifiers excellent components for multiplexing signal selection and mathematical function designs. With 20V/s  slew rate, 20MHz gain bandwidth and low input bias currents make these devices ideal building blocks for signal generators, active filters and data acquisition designs. Programmability, coupled with 9mV maximum offset voltage and 50nA offset current, make these amplifiers outstanding components for signal conditioning circuits
