HR1107CR

Features: ` Fast pulse response: tr, tf = 0.3 ns Typ` High sensitivity: S = 0.8 mA/mW Typ (p = 1550 nm)` Low dark current: IDARK = 1 nA Typ` Low capacitance: Ct = 0.9 pF Typ` Photodetectable area: 80 m DiaSpecifications Item Symbol Rated Value Unit Reverse voltage VR 20 V...

product image

HR1107CR Picture
See larger image
SeekIC No. : 004365420 Detail

HR1107CR: Features: ` Fast pulse response: tr, tf = 0.3 ns Typ` High sensitivity: S = 0.8 mA/mW Typ (p = 1550 nm)` Low dark current: IDARK = 1 nA Typ` Low capacitance: Ct = 0.9 pF Typ` Photodetectable area: 8...

HR1107CR Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
HR1107CR
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/12/24

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

` Fast pulse response: tr, tf = 0.3 ns Typ
` High sensitivity: S = 0.8 mA/mW Typ (p = 1550 nm)
` Low dark current: IDARK = 1 nA Typ
` Low capacitance: Ct = 0.9 pF Typ
` Photodetectable area: 80 m Dia


Specifications

Item
Symbol
Rated Value
Unit
Reverse voltage
VR
20
V
Forward current
IF
5.0
mA
Reverse current
IR
500
A
Operating temperature
Topr
20 to + 70
°C
Storage temperature
Tstg
40 to +85
°C





Description

The HR1107CR is an InGaAs PIN photodiode for detecting light in the 1.0 m to 1.65 m band. Its fast pulse response makes it suitable as an optical signal detector in high-bit-rate fiberoptic communications equipment.
