HMC863

The HMC863 is a three stage GaAs pHEMT MMIC 1/2 Watt Power Amplifi er which operates between 24 and 29.5 GHz. The HMC863 provides 27 dB of gain, and +27 dBm of saturated output power at 18% PAE from a +6V supply.

The features of HMC863 are as follows: (1)Saturated Output Power: +28 dBm @ 18% PAE; (2)High Output IP3: +39 dBm; (3)High Gain: 27 dB; (4)DC Supply: +6V @ 375mA; (5)50 Ohm Matched Input/Output; (6)Die Size: 2.41 x 0.95 x 0.1 mm.

The electrical characteristics of the HMC863 are: (1)Frequency Range: 27 - 29.5 GHz; (2)Gain: 22 dB min and 25 dB typ; (3)Gain Variation Over Temperature: 0.05 dB/ °C; (4)Input Return Loss: 11 dB; (5)Output Return Loss: 11 dB; (6)Output Power for 1 dB Compression (P1dB): 26 dBm; (7)Saturated Output Power (Psat): 27 dBm; (8)Output Third Order Intercept (IP3): 38 dBm; (9)Total Supply Current (Idd): 375 mA.
