Product Details

Description



Features:

• Reduced RFI and EMI
• Reduced Snubbing
• Extensive Characterization of Recovery Parameters
• Hermetic
• Ceramic Eyelets




Specifications

 Parameter
Max.
Units
VR
 D.C. Reverse VoltageTC = 132°C
200
V
IF(AV)
 Continuous Forward Current TC = 25°C ( Per Leg )
16
A
IFSM
 Single Pulse Forward Current ‚
130
PD @ TC = 25°C
 Maximum Power Dissipation
84
W
TJTSTG
 Operating Junction andStorage Temperature Range
-55 to +150
°C





Description

These Ultrafast, soft recovery diodes are optimized to reduce losses and EMI/RFI in high frequency power conditioning systems. An extensive characterization of the recovery behavior for different values of current, temperature and di/dt simplifies the calculations of losses in the operating conditions. The softness of the recovery eliminates the need for a snubber in most applications. These HFB16HY20CC devices are ideally suited for power converters, motors drives and other applications where switching losses are significant portion of the total losses.
