HF10A060ACE

The HF10A060ACE has some electrical characteristics (wafer form).When parameter is VFM,the description is forward voltage,the guaranteed (Min/Max) is 1.7V Max.,the test conditions is TJ = 25,IF = 8.0A.When parameter is BVR,the description is reverse breakdown voltage,the guaranteed (Min/Max) is 600V Min.,the test conditions is TJ = 25,IR = 200A.When parameter is IRM,the description is reverse leakage current,the guaranteed (Min/Max) is 5A Max.,the test conditions is TJ = 25,VR = 600V.

The HF10A060ACE has some mechanical data.The nominal back metal composition,thickness is Cr-Ni-Ag(1 KA - 4 KA - 6 KA).The nominal front metal composition,thickness is 99% Al,1% Si (3 microns).The chip dimensions is 0.090" x 0.090" .The wafer diameter is 125mm,with std.< 100 > flat.The wafer thickness is .015" ± .003".The relevant die mechanical dwg. number is 01-5159.The minimum street width is 100 microns.The reject ink dot size is 0.25 mm diameter minimum.The recommended storage environment is storage in original container, in dessicated nitrogen, with no contamination.
