HD74UH08

` Encapsulated in very small 5pins package of 2.9*1.6 *1.1 mm, the efficiency to mount on substrate is significantly improved.
` The basic gate function is lined up as hitachi uni logic series.
` Supplied on embos taping for high speed automatic mounting.
` Electrical characteristics equivalent to the HD74HC08 Supply voltage range: 2 to 6 V Operating temperature range: 40 to +85°C
` | _IOH | = I_OL = 2 mA (min)

The HD74UH08 is high speed CMOS two input AND gate using silicon gate CMOS process. With CMOS low power dissipation, it provides high speed equivalent to LS-TTL series. The HD74UH08 internal circuit of three stages construction with buffer provides wide noise margin and stable output.
