Features: • The basic gate function is lined up as Renesas uni logic series.• Supplied on emboss taping for high-speed automatic mounting.• TTL compatible input level. Supply voltage range : 3.0 to 5.5 V Operating temperature range : 40 to +85°C• Logic-level translate funct...
HD74LV2GT245A: Features: • The basic gate function is lined up as Renesas uni logic series.• Supplied on emboss taping for high-speed automatic mounting.• TTL compatible input level. Supply volta...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
Item | Symbol | Ratings | Unit | Test Conditi |
Supply voltage range | VCC | 0.5 to 7.0 | V | |
Input voltage range *1 | VI | 0.5 to 7.0 | V | |
Output voltage range *1, 2 | VO | 0.5 to VCC + 0.5 | V | Output : H or L |
0.5 to 7.0 | VCC : OFF | |||
Input clamp current | IIK | -20 | mA | VI < 0 |
Output clamp current | IOK | ±50 | mA | VO < 0 or VO > VCC |
Continuous output current | IO | ±25 | mA | VO = 0 to V |
Continuous current through VCC or GND |
ICC or Land | ±50 | mA | |
Maximum power dissipation at Ta = 25°C (in still air) *3 |
PT | 200 | mW | |
Storage temperature | TSTG | 65 to 150 | °C |
The HD74LV2GT245A has two buffers with three state output in a 8 pin package. When DIR is high, data is transferred from the A inputs to the B outputs, and when DIR is low, data is transferred from the B inputs to the A outputs. The A and B buses are separated by making the enable input (OE) of HD74LV2GT245A high level. The input protection circuitry on HD74LV2GT245A allows over voltage tolerance on the input, allowing the device to be used as a logiclevel translator from 3.0 V CMOS Logic to 5.0 V CMOS Logic or from 1.8 V CMOS logic to 3.0 V CMOS Logic while operating at the high-voltage power supply. Low voltage and high-speed operation is suitable for the battery powered products (e.g., notebook computers), and the low power consumption extends the battery life.
