HCPL-7850

Input Voltage Range (Max) :
Operating Supply Voltage :
Maximum Power Dissipation :
Packaging :
Number of Channels : Single
Maximum Operating Temperature : + 125 C
Input Offset Voltage : 5 mV
Mounting Style : Through Hole
Available Set Gain : 18.06 dB
Package / Case : DIP-8
Minimum Operating Temperature : - 55 C
Common Mode Rejection Ratio (Min) : 69 dB
Supply Current : 15.5 mA


Features:

• Performance Guaranteed over Full Military Temperature Range: 55°C to +125°C
• Manufactured and Tested on a MIL-PRF-38534 Certified Line
• Hermetically Sealed Packages
• Dual Marked with Device Part Number and DSCC Drawing Number
• QML-38534, Class H
• HCPL-7840 Function Compatibility
• High Common Mode Rejection (CMR): 8 kV/ms at VCM = 1000 V
• 5% Gain Tolerance
• 0.1% Nonlinearity
• Low Offset Voltage and Offset Temperature Coefficient
• 100 kHz Bandwidth




Application

• Industrial and Military
• High Reliability Systems
• Harsh Industrial Environments
• Transportation, Medical, and Life Critical Systems
• General Purpose Analog Signal Isolation
• Motor Phase and Rail Current Sensing
• Inverter Current Sensing
• Switched Mode Power Supply Signal Isolation
• General Purpose Current Sensing and Monitoring




Pinout






Specifications

Storage Temperature (TS) ...........................................65 to +150°C
Operating Temperature (TA) .........................................55 to +125°C
Supply Voltages (VDD1, VDD2) ......................................... 0.0 to +5.5 V
Steady-State Input Voltage (VIN+, VIN) .....2.0 V to V_DD1 +0.5 V (1/)
2 Second Transient Input Voltage ............. 6.0 V to V_DD1 +0.5 V (1/)
Output Voltages (VOUT+, VOUT) .........................0.5 to V_DD2 +0.5 V
Lead Soldering Temperature (soldering, 10 seconds max.) ........ +260°C




Description

The HCPL-7850 is commercial grade isolation amplifier that provides accurate, electrically isolated and amplified representations of voltage and current. When used with a shunt resistor to monitor the motor phase current in a high speed motor drive, the device will offer superior reliability compared with the traditional solutions such as current transformers and Hall-effect sensors. This HCPL-7850 device consists of a sigma-delta analog-to-digital converter optically coupled to a digital-to-analog converter in a hermetically sealed 8-Pin ceramic DIP package with gold plated leads. Solder dipped leads and various lead form options are also available. See the datasheet for details.
The products are capable of operation and storage over the full military temperature range and may also be purchased with full MIL-PRF-38534 Class H level testing or from the DSCC SMD 5962-97557. The HCPL-7850 is manufactured and tested on a MIL-PRF-38534 certified line and the Class H version is included in the DSCC Qualified Manufacturers List, QML-38534 for Hybrid Microcircuits.
Superior performance in design critical specifications such as common-mode rejection, offset voltage, nonlinearity, and operating temperature make this product an excellent choice for designing reliable products such as motor controllers and inverters.
Common-mode rejection of 8 kV/micro-second makes the HCPL-7850/7851 suitable for noisy electrical environments such as those generated by the high switching rates of power IGBTs.Low offset voltage together with a low offset voltage temperature coefficient permits accurate use of auto-calibration techniques.Gain tolerance of 5% with 0.1% nonlinearity further provide the performance necessary for accurate feedback and control.

Parameters:

Technical/Catalog Information	HCPL-7850
Vendor	Avago Technologies US Inc.
Category	Integrated Circuits (ICs)
Packaging	Tube
Amplifier Type	Isolation
Number of Circuits	1 - Single
Package / Case	8-CDIP
Slew Rate	-
Gain Bandwidth Product	-
Current - Supply	10.7mA
Current - Output/Channel	14.5mA
Voltage - Supply, Single/Dual (±)	4.5 V ~ 5.5 V
Output Type	-
-3db Bandwidth	100kHz
Current - Input Bias	570nA
Operating Temperature	-55°C ~ 125°C
Voltage - Input Offset	600V
Lead Free Status	Lead Free Compliant by Exemption
RoHS Status	RoHS Compliant by Exemption
Other Names	HCPL 7850 HCPL7850
