HCPL-316J

Isolation Voltage :
Output Type :
Maximum Propagation Delay Time :
Maximum Forward Diode Voltage :
Maximum Reverse Diode Voltage :
Maximum Forward Diode Current :
Maximum Continuous Output Current :
Maximum Power Dissipation :
Maximum Operating Temperature :
Minimum Operating Temperature :
Packaging : Tube
Package / Case : SO-16


Features:

• Drive IGBTs up to
I_C = 150 A, V_CE = 1200 V
• Optically Isolated, FAULT Status Feedback
• SO-16 Package
• CMOS/TTL Compatible
• 500 ns Max. Switching Speeds
• "Soft" IGBT Turn-off
• Integrated Fail-Safe IGBT Protection
Desat (V_CE) Detection
Under Voltage Lock-Out Protection (UVLO) with Hysterisis
• User Configurable:
Inverting, Non-inverting, Auto-Reset, Auto-Shutdown
• Wide Operating V_CC Range:
15 to 30 Volts
• -40°C to +100°C Operating
Temperature Range
• 15 kV/ms Min. Common Mode Rejection (CMR) at
V_CM= 1500 V
• Regulatory Approvals: UL, CSA, IEC/EN/DIN EN 60747- 5-2 (891 Vpeak Working Voltage)

Pinout






Specifications

• Better Resolution
• Better Display Contrast
• Pin-to-pin compatibility
• Wide Message Display Panel With Multi lines is achievable
• Better Operating Cost

Description

Avago's 2.5 Amp Gate Drive Optocoupler with Integrated Desaturation (VCE) Detection and Fault Status Feedback makes IGBTVCW fault protection compact, affordable, and easy-to-implement while satusfying worldwide safety and regulatory requirements.




Parameters:

Technical/Catalog Information	HCPL-316J
Vendor	Avago Technologies US Inc.
Category	Isolators
Type	Gate Drive Optocoupler
Mounting Type	Surface Mount
Package / Case	16-SOIC (7.5mm Width)
Packaging	Tube
Lead Free Status	Contains Lead
RoHS Status	RoHS Non-Compliant
Other Names	HCPL 316J HCPL316J 516 1130 5 ND 51611305ND 516-1130-5
