Product Details

Description



Features:

• Wide range of supply voltage
   Single supply: 2 V to 36 V, Dual supplies: ±1 V to ±18 V
• Very low supply current: 0.6 mA
• Small input bias current: 25 nA
• Small input offset voltage: 2 mV
• Common mode input voltage range includes ground.
• Low output saturation voltage: 200 mV at 4 mA
• Open collector output
• Package outline available in Pb free lead frame:
   DP-8
   SOP-8 (JEITA)
   SOP-8 (JEDEC)


Application

• Battery charger
• Cordless telephone
• Switching power supply
• DC/DC module
• PC motherboard
• Communication equipment


Pinout

Connection Diagram


Specifications

Item Symbol Ratings Unit
HA17393B HA17393BF HA17393BRP
Supply Voltage VCC 36 36 36 V
Differential input voltage VIN (diff) VCC VCC VCC V
Input voltage VIN 0.3 to VCC 0.3 to VCC 0.3 to VCC V
Input current (VIN < 0.3 V) IIN 50 50 50 mA
Power dissipation PT 570 *1 385 *2 385 *2 mW
Output short-circuit to ground   Continuous Continuous Continuous
Operating temperature Topr 40 to +85 40 to +85 40 to +85
Storage temperature Tstg 55 to +125 55 to +125 55 to +125

Notes: 1. This is the allowable value up to Ta = 55. Derate by 8.3 mW/ above that temperature.
           2. These are the allowable values up to Ta = 25 mounting in air. When it is mounted on glass epoxy board of
40 mm * 40 mm * 1.5 mm (t) with 30% wiring density, the allowable value is 570 mW up to Ta = 45.
If Ta > 45, derate by 7.14 mW/.


Description

HA17393B is dual comparators designed for general purpose, especially for power control systems. This HA17393B IC operates from a single power-supply voltage over a wide range of voltages. Operation from split power supply current is also possible and the low power supply current drain is independent of the magnitude of the power supply voltage. These comparators have the merit which ground is included in the common-mode input voltage range at a single-voltage power supply operation.
