HA-A870

• Wide frequency range18.0MHz to 250.0MHz
• User specified tolerance available
• Will withstand vapor phase temperatures of 253°C for 4 minutes maximum
• Space-saving alternative to discrete component oscillators
• High shock resistance, to 3000g
• 3.3Volt operation
• All metal, resistance weld, hermetically sealed package
• Low Jitter
• MECL 10K and 10KH series compatible output on Pin 5, complement on Pin 1
• High Q Crystal actively tuned oscillator circuit
• Power supply decoupling internal
• No internal PLL avoids cascading PLL problems
• High frequencies due to proprietary design
• Gold plated leads - Solder dipped leads available upon request
• RoHS Compliant, Lead Free Construction (unless solder dipped leads are supplied)

The HA-A870 Series of quartz crystal oscillators provide MECL 10K and 10KH series compatible signals in industry standard four pin DIP hermetic package. Systems designers may now specify space-saving, costeffective packaged PECL oscillators to meet their timing requirements.
