SpecificationsFrequency Range3.2768 ~ 90.0MHzDimensions (mm)12.9 x 4.8 x 4.3ConstructionResistance weldDescriptionThe GSX49-4 is designed as SM crystal with 4.3mm maximum height.GSX49-4 has five features. The first one is that it would have wide frequency range. The next one is that it would have ...
GSX49-4: SpecificationsFrequency Range3.2768 ~ 90.0MHzDimensions (mm)12.9 x 4.8 x 4.3ConstructionResistance weldDescriptionThe GSX49-4 is designed as SM crystal with 4.3mm maximum height.GSX49-4 has five fea...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
The GSX49-4 is designed as SM crystal with 4.3mm maximum height.
GSX49-4 has five features. The first one is that it would have wide frequency range. The next one is that it would have low profile case. The next one is that its fundamental mode would be available up to 50.0MHz. The next one is that it would have large stocks of standard frequencies. The next one is that it would have low cost. That are all the main features.
Some important specifications have been concluded into several points as follow. The first one is about its package which would be HC49-4H SMD. The next one is about its frequency range which would be from 3.2768 to 90.0MHz. The next one is about its calibration tolerance which would be ±30ppm. The next one is about its temperature stability which would be ±50ppm. The next one is about its operating temperature range which would be from -10 to +60°C. The next one is about its circuit condition which would be 16pF. The next one is about its oscillation mode which would be fundamental. The next one is about its equivalent series resistance (max) which would be 200 from >3.2 to 3.5MHz and would be 150 from >3.5 to 4.0MHz and would be 120 from >4.0 to 4.4MHz and would be 100 from >4.4 to 7.0MHz and 70 from >7.0 to 10.0MHz and would be 50 from >10.0 to 50.0MHz, fund and would be 100 from >25.0 to 90.0MHz, 3rd OT. The next one is about its static capacitance which would be 7pF max. The next one is about its ageing which would be ±3ppm max first year. The next one is about its test drive level which would be 100W.
Something should be noted that GSX49-4 would be available on T&R - 1k pcs per reel. Refer to our website for T&R and soldering details. And it would be the lowest cost SMD crystal. and so on. For more information please contact us.
