Memory Size: -
Features: -
Operating Temperature: -40°C ~ 85°C
Data Rate - Maximum: -
Frequency: 1575.42MHz
Manufacturer: RF Solutions
Packaging: Bulk
Applications: GPS
Package / Case: Module
Supplier Device Package: Module
Series: XE1610
Sensitivity: -143dBm
Modulation or Protocol: CDMA
Current - Receiving: 17mA
Data Interface: Connector, 16 Contact Board to Board
Antenna Connector: Subminiature HFL
Voltage - Supply: 3 V ~ 3.65 V
Features: • High sensitivity: to -143 dBm tracking, superior urban performance.
• Position accuracy: < 5m CEP (50%) without SA (horizontal)
• Warm Start is under 40 seconds (50%)
• Hot Start is under 12 seconds (50%)
• Ultra low power: < 20 mA @ 3.3V full power, 3 additional low power modes
• Embedded ARM7TDMI
• Small form factor and low cost solution
• Ready-to-plug solution, fully autonomous PVT solution. Easily integrated into existing systems
• On-board RAM for GPS navigation data, on-board Flash memory back-up
• PPS output
• Bidirectional NMEA interface
• Real Time Clock with separate back-up power supplyApplication• Automotive
• Asset management/tracking
• Palmtop, Laptop, PDA
• Location Based Services enabled devices
• Handheld receivers
DescriptionThe XE1610-OEMPVT GPS Receiver from RF Solutions is a GPS receiver product which features the revolutionary FirstGPS™ architecture. This complete GPS receiver solution XE1610-OEMPVT provides high accuracy position and speed performance as well as high sensitivity and tracking capabilities in urban areas. The GPS Receiver comes in a small form factor package. The XE1610- OEMPVT delivers major advancements in GPS performance, accuracy, integration, computing power and flexibility. It is designed to simplify the embedded system integration process.
The XE1610-OEMPVT is a mixed hardware/software architecture based on the XE16BB10 advanced channel correlator IC and its companion RF downconverter.
Parameters: | Technical/Catalog Information | GPSM001 |
| Vendor | RF Solutions |
| Category | RF and RFID |
| Frequency | 1.575GHz |
| Data Rate - Maximum | - |
| Modulation or Protocol | GPS |
| Applications | Automotive, PDA |
| Power - Output | - |
| Sensitivity | -143dBm |
| Voltage - Supply | 3V ~ 3.65V |
| Current - Receiving | - |
| Current - Transmitting | - |
| Package / Case | Module |
| Operating Temperature | -40°C ~ 85°C |
| Data Interface | Connector, 16 Contact Board to Board |
| Antenna Connector | - |
| Packaging | Bulk |
| Memory Size | - |
| Drawing Number | * |
| Lead Free Status | Contains Lead |
| Other Names | GPSM001
