See larger image

SeekIC No. : 00134318 Detail

GBU6K-BP: Bridge Rectifiers 6A 800V

GBU6K-BP Data Sheet

US $ .32~.45 / Piece | Get Latest Price

Part Number:: GBU6K-BP
Mfg:: Micro Commercial Components (MCC)
Supply Ability:: 5000

Price Break

Qty
0~1000
1000~5000
5000~10000

Unit Price
$.45
$.38
$.32

Processing time
15 Days
15 Days
15 Days

View more price & deliveries

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2024/11/13

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

GBU60010 evaluate
Features: . Glass Passivated Die Construction. High Case Dielectric Strength of 1500VRMS. Low Reve...
GBU6005 evaluate
US $.62 - 1.01 / Piece

Bridge Rectifiers 6.0A 50V
GBU6005-G evaluate
US $.3 - .3 / Piece

RECTIFIER BRIDGE 6A 50V GBU

Product Details

Quick Details

Product :	Single Phase Bridge	Peak Reverse Voltage :	800 V
Maximum RMS Reverse Voltage :	560 V	Max Surge Current :	175 A
Forward Voltage Drop :	1 V	Maximum Reverse Leakage Current :	5 uA
Maximum Operating Temperature :	+ 150 C	Length :	22.3 mm
Width :	3.56 mm	Height :	18.8 mm
Mounting Style :	Through Hole	Package / Case :	GBU
Packaging :	Tube

Description

Forward Continuous Current :
Power Dissipation :
Product : Single Phase Bridge
Maximum Operating Temperature : + 150 C
Mounting Style : Through Hole
Packaging : Tube
Peak Reverse Voltage : 800 V
Maximum RMS Reverse Voltage : 560 V
Maximum Reverse Leakage Current : 5 uA
Forward Voltage Drop : 1 V
Length : 22.3 mm
Width : 3.56 mm
Height : 18.8 mm
Package / Case : GBU
Max Surge Current : 175 A

Parameters:

Technical/Catalog Information	GBU6K-BP
Vendor	Micro Commercial Co
Category	Discrete Semiconductor Products
Diode Type	Single Phase
Package / Case	GBU
Packaging	Tube
Reverse Recovery Time (trr)	-
Speed	Standard Recovery >500ns, > 200mA (Io)
Current - DC Forward (If)	6A
Voltage - Peak Reverse (Max)	800V
Mounting Type	Through Hole
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	GBU6K BP GBU6KBP GBU6K BPMS ND GBU6KBPMSND GBU6K-BPMS
