G3VM-351G

Solid State Relays 350V, SPST-NO, SOP4 SMT 110mA 35ohm 30pF

product image

G3VM-351G Picture
See larger image
SeekIC No. : 0090729 Detail

G3VM-351G: Solid State Relays 350V, SPST-NO, SOP4 SMT 110mA 35ohm 30pF

G3VM-351G Data Sheet

floor Price/Ceiling Price

US $ 1.21~1.54 / Piece | Get Latest Price
Part Number:
G3VM-351G
Mfg:
Omron Electronics
Supply Ability:
5000

Price Break

  • Qty
  • 0~1
  • 1~25
  • 25~50
  • 50~100
  • Unit Price
  • $1.54
  • $1.43
  • $1.36
  • $1.21
  • Processing time
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/17

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Product Type : PCB Mount Mounting Style : SMD/SMT
Control Voltage Range : 1 V to 1.3 V Load Voltage Rating : 350 V
Load Current Rating : 110 mA Contact Form : 1 Form A (SPST-NO)
Output Device : MOSFET Package / Case : SOP-4

Description

Product Type : PCB Mount
Mounting Style : SMD/SMT
Contact Form : 1 Form A (SPST-NO)
Output Device : MOSFET
Control Voltage Range : 1 V to 1.3 V
Package / Case : SOP-4
Load Voltage Rating : 350 V
Load Current Rating : 110 mA


Application

* Broadband systems
* Measurement devices
* Data loggers
* Amusement machines


Specifications

Item
Symbol
Rating
Unit
Measurement Conditions
Input
LED forward current
IF
50
mA
Repetitive peak LED forward
current
IFP
1
A
100 s pulses, 100 pps
LED forward current reduction
rate
IF/
-0.5
mA/
Ta 25
LED reverse voltage
VR
5
V
Connection temperature
Tj
125
Output
Output dielectric strength
VOFF
350
V
Continuous load current
IO
110
mA
ON current reduction rate
ION /
-1.1
mA/
Ta 25
Connection temperature
Tj
125
Dielectric strength between inputand
output (See note 1.)
V I-O
1,500
Vrms
AC for 1 min
Operating temperature
Ta
-40to +85
With no icing or condensation
Storage temperature
Tstg
-55to+125
With no icing or condensation
Soldering temperature (10 s)
---
260
10 s



Parameters:

Technical/Catalog InformationG3VM-351G
VendorOmron Electronics Inc-ECB Div
CategoryRelays
Mounting TypeSurface Mount
Termination StyleGull Wing
Package / Case4-SOP
CircuitSPST-NO (1 Form A)
Load Current110mA
Voltage - Input1.15VDC
Voltage - Load0 ~ 350 V
Output TypeAC, DC
On-State Resistance35 Ohm
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names G3VM 351G
G3VM351G
Z2084 ND
Z2084ND
Z2084
