IGBT Modules 60V 1A 15kHz
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
Configuration : | 3-Phase | Continuous Collector Current at 25 C : | 2.6 A | ||
Power Dissipation : | 11 W | Maximum Operating Temperature : | + 125 C | ||
Package / Case : | SPM23-BA | Packaging : | Reel |
Product | Product status | Eco Status | Pricing* | Package type | Leads | Packing method | Package Drawing | Package Marking Convention** |
---|---|---|---|---|---|---|---|---|
FSB52006S | Full Production | RoHS Compliant | $4.94 | SPM23-BA | 23 | TAPE REEL | N/A | Line 1: $Y (Fairchild logo) Line 2: FSB52006S Line 3: &H&E&E&E&3 |
* Fairchild 1,000 piece Budgetary Pricing |
** A sample button will appear if the part is available through Fairchild's on-line samples program. If there is no sample button, please contact a Fairchild distributor to obtain samples |
Package marking information for product FSB52006S is available. Click here for more information . |
FSB52006S is a tiny smart power module (SPM) based onFRFET technology as a compact inverter solution for smallpower motor drive applications such as fan motors and watersuppliers. It is composed of 6 fast-recovery MOSFET (FRFET),and 3 half-bridge HVICs for FRFET gate driving. FSB52006Sprovides low electromagnetic interference (EMI) characteristicswith optimized switching speed. Moreover, since it employsFRFET as a power switch, it has much better ruggedness andlarger safe operation area (SOA) than that of an IGBT-basedpower module or one-chip solution. The package is optimizedfor the thermal performance and compactness for the use in thebuilt-in motor application and any other application where theassembly space is concerned. FSB52006S is the most solutionfor the compact inverter providing the energy efficiency,compactness, and low electromagnetic interference.VBS High-side Bias Voltage Applied between VB(U)-VS(U), VB(V)-VS(V),R?JC Junction to Case Thermal Resistance Each FRFET under inverter operating conditionVISO Isolation Voltage 60Hz, Sinusoidal, 1 minute, Connection
Technical/Catalog Information | FSB52006S |
Vendor | Fairchild Semiconductor |
Category | Integrated Circuits (ICs) |
Applications | AC Motor Driver, 3 Phase |
Number of Outputs | 1 |
Voltage - Supply | 13.5 V ~ 16.5 V |
Voltage - Load | 45 V ~ 55 V |
Current - Output | 2.6A |
Operating Temperature | -20°C ~ 100°C |
Package / Case | SPM23BA |
Packaging | Tube |
Lead Free Status | Lead Free |
RoHS Status | RoHS Compliant |
Other Names | FSB52006S FSB52006S |
