Features: • 8-bit resolution• 150 megapixels per second 0.2% linearity error• Sync and blank controls• 1.0V p-p video into 37.5Ωor 75Ωload• Internal bandgap voltage reference• Double-buffered data for low distortion• TTL-compatible inputs̶...
FMS3815: Features: • 8-bit resolution• 150 megapixels per second 0.2% linearity error• Sync and blank controls• 1.0V p-p video into 37.5Ωor 75Ωload• Internal bandga...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
Parameter | Min | Typ | Max | Unit |
Power Supply Voltage | ||||
VDD(Measured to GND) | -0.5 | 7.0 | V | |
Inputs | ||||
Applied Voltage (measured to GND)2 |
-0.5 | VDD+ 0.5 | V | |
Forced Current3,4 |
-10.0 | 10.0 | mA | |
Outputs | ||||
Applied Voltage (measured to GND)2 |
-0.5 | VDD+ 0.5 | V | |
Forced Current3,4 | -60.0 | 60.0 | mA | |
Short Circuit Duration (single output in HIGH state to ground) | unlimited | sec. | ||
Temperature | ||||
Operating, Ambient | -20 | 110 | °C | |
Junction | 150 | °C | ||
Lead Soldering (10 seconds) | 300 | °C | ||
Vapor Phase Soldering (1 minute) | 220 | °C | ||
Storage | -65 | 150 | °C |
