FMGA-461 0.8 Amps

The FMGA-461 EMI filters reduce the reflected input ripple current of Interpoint's high frequency surface mount DC/DC converters. One filter can be used with multiple converters up to the rated output current of the filter.

The FMGA-461 are available with standard screening, "ES" screening, or fully compliant to "883" MIL-PRF-38534 Class H screening. DSCC drawings are available.

Surface mount package, 0.89 in² (5.73 cm²)

FMGA-461 Attenuation 55 dB at 500 kHz

• Operating temperature -55° to +125°C
• Nominal 28 V input, 0 V to 50 V operation
• Up to 0.8 A throughput current
• Compatible with MIL-STD-704 A-E 28 VDC power bus
• Compliant to MIL-STD-461C CE-03
• Compatible with MGA and MGH Series of converters
• Case size 1.010 * 0.880 * 0.250 inches (25.65 * 22.35 * 6.35 mm)
