FLK207MH-14

Features: • High Output Power: P1dB = 32.5dBm(Typ.)• High Gain: G1dB = 6.0dB(Typ.)• High PAE: add = 27%(Typ.)• Proven Reliability• Hermetic Metal/Ceramic PackageSpecifications Item Symbol Condition Rating Unit Drain-Source Voltage VDS 1...

product image

FLK207MH-14 Picture
See larger image
SeekIC No. : 004342070 Detail

FLK207MH-14: Features: • High Output Power: P1dB = 32.5dBm(Typ.)• High Gain: G1dB = 6.0dB(Typ.)• High PAE: add = 27%(Typ.)• Proven Reliability• Hermetic Metal/Ceramic PackageSpecifi...

FLK207MH-14 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
FLK207MH-14
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/12/21

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

• High Output Power: P1dB = 32.5dBm(Typ.)
• High Gain: G1dB = 6.0dB(Typ.)
• High PAE: add = 27%(Typ.)
• Proven Reliability
• Hermetic Metal/Ceramic Package


Specifications

Item
Symbol
Condition
Rating
Unit
Drain-Source Voltage
VDS
15
V
Gate-Source Voltage
VGS
-5
V
Total Power Dissipation
PT
Tc = 25°C
12.5
W
Storage Temperature
Tstg
-65 to +175
Channel Temperature
Tch
175
Fujitsu recommends the following conditions for the reliable operation of GaAs FETs:
1. The drain-source operating voltage (VDS) should not exceed 10 volts.
2. The forward and reverse gate currents should not exceed 17.8 and -1.0 mA respectively with gate resistance of 250.
3. The operating channel temperature (Tch) should not exceed 145°C.


Description

The FLK207MH-14 is a power GaAs FET that is designed for general purpose applications in the Ku-Band frequency range as it provides superior power, gain, and efficiency.

Fujitsu's stringent Quality Assurance Program of FLK207MH-14 assures the highest reliability and consistent performance.
