FAN5066

• Output adjustable from 400mV to 3.5V
• Synchronous Rectification
• Adjustable operation from 80KHz to 1MHz
• Integrated Power Good and Enable functions
• Overvoltage protection
• Overcurrent protection
• Drives N-channel MOSFETs
• 20 pin SOIC or TSSOP package

The FAN5066 is a synchronous mode DC-DC controller IC which provides an adjustable output voltage for ultra-low voltage applications, down to 400mV. The FAN5066 uses a high level of integration to deliver load currents in excess of 19A from a 5V source with minimal external circuitry. Synchronous-mode operation offers optimum efficiency over the entire output voltage range, and the internal oscillator can be programmed from 80KHz to 1MHz for additional flexibility in choosing external components. The FAN5066 also offers integrated functions including a four-bit DAC-controlled reference, Power Good, Output Enable, over-voltage protection and current limiting.
