EZGPM01

Features:

`Fully self-contained 12 channel GPS receiver
`Fully EMI shielded
`SiRFstar™ IIe/LP architecture
`GRF2i/LP RF front-end IC
`GSP2e/LP GPS Engine with Integrated Processor
`SBAS(Satellite Based Augmentation System) support
`Fast time-to-first-fix
`8Mbit Flash memory
`Built-in Low-noise amplifier
`Advanced low power modes
`Operating Voltage 3.3V
`Battery supply pin for internal backup memory and real time clock
`Passive and active antenna support
`Active antenna bias supply voltage pin
`Active antenna overcurrent protection
`Industrial operating temperature range -40ºC .85ºC
`Very compact : 25.4 X 25.4 X 3 mm


Application

·Navigation
·Aviation
·Automotive applications
·Location Based Services
·Timing applications


Pinout




Specifications

Parameter	Symbol	Min	Max	Units
Power Supply Voltage	Vcc		6	V
Input Pin Voltage	Vin		5	V
Antenna Bias Current	Iant		100	mA
Storage Temperature	Tstg	-55	+125	ºC

Description

The EZGPM01 GPS Receiver is a fully selfcontained single-board 12 channel parallel receiver module intended as a component for OEM Global Positioning System(GPS).

Based on the SiRFstar™IIe/LP architecture, the module provides complete GPS signal processing, thus providing accurate satellite position data.

The EZGPM01 is a completely shielded module.
